YSTC583G
Yuan Shan
YSTC583G
Data Transfer+External Storage
Keep a compatible NVMe SSD in a slim black enclosure that travels with your computer. The YSTC583G combines an aluminum alloy and ABS housing with an 8 mm profile and 50 g product weight. A USB-C connection with a USB 3.2 interface rated up to 10Gbps provides external access to your selected M.2 NVMe drive.
Black aluminum alloy and ABS housing
105 x 32 x 8 mm body; 50 g weight
USB 3.2 interface rated up to 10Gbps
NVMe only; SSD not included
Available color for YSTC583G: Black. SSD not included.
The YSTC583G uses a black housing made from aluminum alloy and ABS. Its simple appearance suits a laptop accessory kit or a compact desk setup, with the material and finish stated clearly for product selection.
This listing is for the black version of the enclosure. Choose the drive separately to complete your external-storage setup.
At 105 x 32 x 8 mm, this slim M.2 NVMe SSD enclosure has a flat, narrow shape that fits alongside a laptop and other accessories. The enclosure weighs 50 g, keeping the accessory itself light to carry between locations.
Its 30 cm cable suits a close connection to a compatible computer, so the drive can stay within reach when you need access to your files.
Connect the installed NVMe SSD to your computer through USB-C for working files, media libraries or backups. The USB 3.2 interface is rated up to 10Gbps, providing the stated connection capability for your external-storage build.
The host port and cable must also support a 10Gbps data connection to use the full USB interface capability.
Supported SSD sizes are M.2 2230, 2242, 2260 and 2280, with M-Key or B+M Key connectors on compatible PCIe NVMe drives. This allows you to select from four module lengths while keeping the same enclosure model.
The YSTC583G is designed for NVMe SSDs. It does not support M.2 SATA drives, even if a SATA drive has a similar B+M Key connector.
Build your storage around the capacity you need, using a compatible NVMe SSD up to 8TB. You can select a drive for a portable file collection or a separate backup library.
Only the enclosure is supplied. An SSD is required separately, and its capacity determines the storage available in use.
10Gbps is an interface rating, not a guaranteed file-copy speed. Actual results depend on the SSD, host connection, cable and workload. This model supports PCIe NVMe SSDs only.
For product or order enquiries, quote YSTC583G and share your NVMe SSD specification and required quantity with Yuan Shan.
